Hazet 5145-3CT Torque Wrench, 300-800 Nm, 20mm (3/4") Square
General Information
Brand
Hazet
Part Number
5145-3CT
Product Type
Torque wrench
Packaging
Retail
Country of Origin
Germany
UPC
4000896218929
California Residents
Proposition 65 Warning
Return Policy
NCNR - Non-Cancellable / Non-Returnable
Physical Characteristics
Color
Black / Blue
Length
1271 mm
Weight
6.70 kg
14.77 lb
Details
Wrench Type
Torque
Type
Square, solid
Size
20 mm (3/4 inch)
Features
DIN 3120, ISO 1174-1, DIN EN ISO 6789-2:2017
Tolerance: 3 %
Scale Graduation (Nm): 2.5 Nm
Effective torque wrench length min.-max. I1 mm: 1169.00 – 1149.00 Nm
Actuating force min.-max. kg: 26.2 – 71.0 kg
Number of teeth: 32 (Opening angle 11.25°)
Head Thickness a: 28.5 mm
Head Width b: 64 mm
Tolerance: 3 %
Scale Graduation (Nm): 2.5 Nm
Effective torque wrench length min.-max. I1 mm: 1169.00 – 1149.00 Nm
Actuating force min.-max. kg: 26.2 – 71.0 kg
Number of teeth: 32 (Opening angle 11.25°)
Head Thickness a: 28.5 mm
Head Width b: 64 mm
Torque Range Nm
300 – 800 Nm
General Information
Brand
Hazet
Part Number
5145-3CT
Product Type
Torque wrench
Packaging
Retail
Country of Origin
Germany
UPC
4000896218929
California Residents
Proposition 65 Warning
Return Policy
NCNR - Non-Cancellable / Non-Returnable
Physical Characteristics
Color
Black / Blue
Length
1271 mm
Weight
6.70 kg
14.77 lb
Details
Wrench Type
Torque
Type
Square, solid
Size
20 mm (3/4 inch)
Features
DIN 3120, ISO 1174-1, DIN EN ISO 6789-2:2017
Tolerance: 3 %
Scale Graduation (Nm): 2.5 Nm
Effective torque wrench length min.-max. I1 mm: 1169.00 – 1149.00 Nm
Actuating force min.-max. kg: 26.2 – 71.0 kg
Number of teeth: 32 (Opening angle 11.25°)
Head Thickness a: 28.5 mm
Head Width b: 64 mm
Tolerance: 3 %
Scale Graduation (Nm): 2.5 Nm
Effective torque wrench length min.-max. I1 mm: 1169.00 – 1149.00 Nm
Actuating force min.-max. kg: 26.2 – 71.0 kg
Number of teeth: 32 (Opening angle 11.25°)
Head Thickness a: 28.5 mm
Head Width b: 64 mm
Torque Range Nm
300 – 800 Nm
$804.65
Original: $2,299.00
-65%Hazet 5145-3CT Torque Wrench, 300-800 Nm, 20mm (3/4") Square—
$2,299.00
$804.65Description
